|Frequency Range:||52.5~47.5HZ||Power Supply:||AC220V , DC110V|
|Operating Oil Pressure:||6.4Mpa,16Mpa||Application:||Hydro Turbine Speed Control|
|Control Type:||PLC Program Control|
micro hydro turbine generator,
hydraulic turbine governor
50HZ Hydro Turbine Governor For Pelton Hydro Turbine
PLC governor for hydro turbine generator unit.
l PLC governor for hydro turbine generator unit
l Power supply: AC220V;DC110V
l Operating oil pressure: 6.4Mpa
l Range of adjustment for nozzle servomotor opening/closing time: 10 - 60s
l Range of adjustment for deflector servomotor opening/closing time: <2.0s
l PIDRegulator Parameter Setting Range:
l momentary speed droop: 0~ 200%
l Permanent speed droop: 0~10%
i Integral Gain Td: 0~20s
l Acceleration time constant: 0 - 5s
l Frequency range: 52.5~47.5HZ
This series of PLC governor are suitable to various medium and small turbine generator sets. It is produced according to standards of GB/T9652.1-1997.
This governor designed upon advanced hydraulic technology and PLC control technology, achieve the hydro turbine automatic regulation and control.
Function: Regulate the turbine speed, Adjust the frequency of generator set, track the frequency of power supply network and control phase. Safety protection in case of emergent stop.
This PLC governor have two series: CJWT Type which control the impact turbine, like Pelton turbine, Turgo turbine etc.
This PLC governor used to regulate and control the hydro turbine/water turbine speed, steady the generator frequency at 50HZ or 60HZ.
The governor can operate in full automatic control or manual field/ remote control.
Function: PID regulator, frequency output, power adjustment, speed adjustment, openning limited, automatic tracking grid system frequency, self-diagnosis, fault tolerance etc.
