Pelton Hydro Turbine With Synchronous Generator,Excitation,PLC Governor,Valve

Pelton Hydro Turbine With Synchronous Generator,Excitation,PLC Governor,Valve
Pelton Hydro Turbine With Synchronous Generator,Excitation,PLC Governor,Valve Pelton Hydro Turbine With Synchronous Generator,Excitation,PLC Governor,Valve Pelton Hydro Turbine With Synchronous Generator,Excitation,PLC Governor,Valve Pelton Hydro Turbine With Synchronous Generator,Excitation,PLC Governor,Valve Pelton Hydro Turbine With Synchronous Generator,Excitation,PLC Governor,Valve

Large Image :  Pelton Hydro Turbine With Synchronous Generator,Excitation,PLC Governor,Valve

Product Details:
Place of Origin: Zhejiang,China
Brand Name: Hydrotu
Certification: CE
Model Number: Pelton water Turbine
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wooden Case( Export Standard Package)
Delivery Time: Negotiable
Payment Terms: L/C,T/T

Pelton Hydro Turbine With Synchronous Generator,Excitation,PLC Governor,Valve

Description
Turbine Type: Pelton Hydro Turbine Water Head: 80m-800m
Capacity: 100KW-20000KW Runner Material: Casting Stainless Steel 0Cr13Ni4Mo
High Light:

hydro power turbine

,

hydro water turbine

,

pelton turbine with synchronous generator

Pelton Hydro Turbine / Pelton Water Turbine with Synchronous Generator, Speed Governor, Inlet Valve



Descrition:



The Pelton turbine is widely used in hydropower station with the heads from 80-1600m.

Pelton turbine is consisted of runner, turbine case, nozzles assembly, inlet pipe, deflector etc. The runner is assembled in the shaft of the generator, torque transmission by ping.

.lt utilizes the dynamic power of high pressure water flow to rotate the runner and force the rotor work, The centre line of the jet is in the same plane as the runner while rotating.

Pelton turbine has the advantages of compact construction, stable running and easy operation. Normally, Small pelton turbine always arranged with horizontal shaft and one or two nozzles,   Medium size and larger Pelton turbines are most often arranged with vertical shaft, and equip four or six nozzles to obtain more power.



Applications:



1.     Water head:  80m - 1000m

2.      Power: 500kw - 20000KW

3.     Frequency: 50/60hz

4.     Generator Output voltage: 0.4KVV, 6.3KV, or 10.5KV AC three phase,



If you are interested in the Pelton turbine, you should send some key parameters (such as net head, flow discharge, unit number, frequency, voltage) in inquiry.



We can supply pelton turbine generator above 500KW, supply the runner with Forge and CNC machine, or runner with cast abrading machine for your require.



Specifications:



Type

Horizontal pelton turbine with one /two nozzles

Vertical pelton turbine with four nozzles

Water head

 80m - 1000m.

Installation capacity

 0.5MW - 20MW

Runner material

Stainless steel (0Cr13Ni4Mo)

Cast machine/Forge + CNC machine

Generator type

Synchronous generator

Auxiliary Equipment

Governor, Inlet Valve, unit side panel, excitation system





Competitive Advantage:



HYDROTU is the complete Chinese hydropower equipment supply, consulting and engineering design venture in the field of hydropower equipment. We provide the high quality Chinese hydropower equipment with advanced technologies and integrated services to meet the global hydropower markets.



With our Integrated Services concept, we provide you with customized support from project planning through implementation to plant commissioning and service. Our principle: Customer’s project is our project , customer’s success is our success.



HYDROTU covers the services, complete equipment supply, economic solution of the global hydropower projects and aims to be the best global supplier of hydropower equipment as well as the best integrated services provider on the hydropower markets.



Pelton Turbine Runner



Pelton Hydro Turbine With Synchronous Generator,Excitation,PLC Governor,Valve 0

Pelton Hydro Turbine With Synchronous Generator,Excitation,PLC Governor,Valve 1
