Technical Specifications and Main Parameters of EGER HEPP 2x960KW Hydropower Plant
| Basic Parameter | technical specification |
|---|---|
| Model | Horizontal shaft Francis turbine,HLA551C-WJ-84 |
| Rated water head | H=26m |
| Rated Discharge | Q=4.5m3/s |
| Rated Output power | P=960KW |
| Rated efficiency: | η=92.6%, GENERATOR: 94.8% |
| Rated speed: | n=500 rpm |
| Runner diameter | D1=84cm |
| Runner blades material: | Stainless steel (0Cr13Ni4Mo) |
| Rotary direction | Clockwise viewed from generator to turbine |
