Product Details:
|
| Type: | Kaplan Turbine | Water Head: | 2m-25 M |
|---|---|---|---|
| Capacity Of Alternator: | 100KW To 1000KW | Blades Material: | Stainless Steel CA6NM |
| Hub Material: | Carbon Steel | Generator Voltage: | 6300V |
| Runner Diameter: | Below 2m | Guide Vanes Material: | ZG20SiMn |
The Kaplan Water Turbine Generator also features oil braking with flywheel which allows for improved stability and greater control during operation. This feature is especially useful when sudden surges or fluctuations in the water flow occur.
The guide vanes material used in the Kaplan Hydro Turbine is ZG20SiMn or stainless steel, which provides excellent resistance to corrosion and erosion. The guide vanes play a critical role in ensuring that the water flow is directed towards the turbine blades, which then converts the energy of the water into mechanical energy.
Overall, the Kaplan Hydro Turbine is a reliable and efficient piece of equipment that can generate a significant amount of power. Its ability to operate in a wide range of water heads makes it a versatile option for a variety of applications. If you're looking for a dependable hydro turbine that can deliver consistent performance, the Kaplan Hydro Turbine is definitely worth considering.
| Technical Parameter | Value |
|---|---|
| Type | Kaplan Turbine |
| Water Head | 2m-25m |
| Runner Diameter | Below 2m |
| Runner Blade Angle | 15°-30° |
| Blades Material | Stainless Steel 0Cr13Ni4Mo |
| Guide Vanes Material | ZG20SiMn |
| Control System | Governor or Electronic Controller |
| Brake Mode | Oil Braking (with Flywheel) |
| Housing | Carbon Steel |
| Capacity of Alternator | 100KW to 1000KW |
This is an Adjustable Blade Hydro Turbine with a Vertical shaft Type Hydro Turbine design, commonly known as a Kaplan Water Turbine Generator.
The Kaplan Waterwheel Turbine is suitable for a wide range of applications, including hydroelectric power stations, small and medium-sized hydropower plants, and water treatment facilities. It is also ideal for use in irrigation systems, as well as for industrial and agricultural purposes.
The HYDROTU Kaplan turbine is manufactured in China, ensuring a high level of quality and reliability. Its runner diameter is below 2m, making it a compact and efficient turbine that can be easily installed in various locations.
The oil braking (with flywheel) mode of the HYDROTU Kaplan turbine ensures safe and reliable operation, while also providing a stable and precise control of the turbine's speed. This feature makes it ideal for use in situations where precise control is required, such as in water treatment plants.
In summary, the HYDROTU Kaplan turbine is a versatile and efficient water turbine that can be used in a variety of occasions and scenarios. Its adjustable blade hydro turbine design, combined with its high-quality materials and reliable braking system, make it an ideal choice for energy generation and other applications.
Customize your Kaplan Hydro Turbine with HYDROTU, a propeller type hydro turbine with vertical design. Originating from China, this turbine comes with a carbon steel hub material and ZG20SiMn guide vanes material. Choose between a governor hydraulic controller as the speed governor system for your turbine. the speed governor can adjust the runner blade angle between 15° to 30° to fit your specific needs.
